1-3
System Description and Terminology
Product Support: www.instron.com
Components
The major components of an Instron electromechanical testing system include:
• Load frame with integral controller
• Load cell mounted to the crosshead
• Grips for tension testing or table-mounted anvils on a platen for compression testing.
• Instron approved computer system with Instron Bluehill
®
software.
Front View Rear View
Figure 1-2. 5988 and 5989 Dual Column Floor Frames
