Accessory Mounting Dimensions
Product Support: www.instron.com
Accessory Mounting Dimensions
You can attach numerous testing accessories and fixtures to the load frame for specialized
tests. Use the standard mounting holes shown in the following diagrams to mount your
accessories. Avoid tapping new holes that may weaken or otherwise compromise the
integrity of the load frame.
All measurements in the following figures are shown in mm.
