Series 5980 Optional Configurations
Product Support: www.instron.com
Series 5980 Optional Configurations
In addition to the standard height, standard width model with a single test space below the
moving crosshead, 5982, 5984 and 5985 load frames are available in several frame options
for specialized testing, as follows:
• Extra wide - for large assemblies
• Extra height - for unusually long specimens
• Second test space - lets you test above the moving crosshead
5988 and 5989 load frames are available in standard configurations only.
Table 2-4 on page 2-11 summarizes the options and combination of options that are
available.
5982, 5984 and 5985 Dimensions
Standard, Extra Height and Extra Wide Options
Figure 2-2 on page 2-12 shows the frame dimensions. Refer to Table 2-5 on page 2-13
and Table 2-6 on page 2-13 to match the letter designations.
Table 2-4. 5980 Optional Frame Combinations
Optional
Configuration
Load Frame Model
5982 5984 5985
5988 and
5989
Extra Wide Yes Yes Yes No
Extra Height Yes Yes Yes No
Extra Wide + Extra
Height
Yes Yes Yes No
Second Test Space Yes Yes Yes No
Extra Height with
Second Test Space
Yes Yes Yes No
