Instron 5985 - Page 42

Chapter: Requirements and Specifications
2-22 M10-16250-EN
Crosshead
Figure 2-9. 5982 Moving Crosshead Mounting Dimensions
482
280
140
45
90
M10 x 25 Deep
(10X)
Ø100
Ø11 Thru
(6X)
Front of frame
Topside of moving crosshead
Ø40 x 3 Deep
M16 x 35 Deep
(2X)
90
45
140
280
M10 x 25 Deep
(10X)
Front of frame
Underside of moving crosshead
Ø100
Ø40 x 3 Deep
Ø32 Thru
