Accessory Mounting Dimensions
Product Support: www.instron.com
Top Plate
The top plate is not a load bearing component of the machine.
Figure 2-14. 5980 Series Top Plate Mounting Dimensions
280
90
M10 Threaded
inserts (4X)
