Chapter: Maintenance
5-12 M10-16250-EN
5989 Frame
Fuse, 2A Slo-blo, 6.3 x 32mm
glass
27-2-13 1 Protection from electrical surges
Cable clip, 6-12 mm 11-6-60 6 Secures cables to the frame
Nut, M5 T-slot clip 52-59-1011 6 Installing accessories onto the column
cover
Accessories slot T-nut T1697-1307 6 Installing accessories onto the column
cover
10 MTS Ground cable A712-213-3 1 Used to connect the frame to a
suitable ground where the mains
power supply is not grounded
Locating ring type 2 T1335-1052 1 Locating ring for load cell- 60mm
diameter for M48 thread
Superbolt nut, M48 x 2P 52-2-75 1 To attach and preload load cell
Draw bar M48 x 2 RH T620-505 1 Used with superbolt nut to attach load
cell to crosshead
Transducer cable assembly, 2.5 m A1735-1360-1 1 Load cell extension cable
Table 5-4. 5988 Ancillary Parts
Description
Part
Number Quantity Purpose
Table 5-5. 5989 Ancillary Parts
Description
Part
Number Quantity Purpose
Cable Ethernet Cat5E 10ft
Crossover
144-1-1052 1 Connects the frame controller to the
computer
Hex wrench key set,
1.5 to 10 mm
80-1-1011 1 Tools for maintaining the frame and
installation of accessories
Fuse, 2A Slo-blo, 6.3 x 32mm
glass
27-2-13 1 Protection from electrical surges
Cable clip, 6-12 mm 11-6-60 6 Secures cables to the frame
Nut, M5 T-slot clip 52-59-1011 6
Accessories slot T-nut T1697-1307 6 Installing accessories onto the column
cover
