Integra ADM-2.1 User Manual

W0008-1
E
SN 29343005
Integra Division of
ONKYO U.S.A. CORPORATION
200 Williams Drive, Ramsey, N.J. 07446, U.S.A.
Tel: 201-825-7950 Fax: 201-825-8150 E-mail: integra@onkyousa.com
Integra Division of
ONKYO CORPORATION
Sales & Product Planning Div. :
2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: 072-831-8111 Fax: 072-833-5222
Specifications
AMPLIFIER SECTION
Power Output: 100 Watts per channel min. RMS at
8 ohms, both channel driven from
20 to 20,000 Hz with no more than
0.08 % total harmonic distortion.
125 Watts per channel min. RMS at
6 ohms, both channel driven from
1 kHz with no more than 0.1 %
total harmonic distortion.
Dynamic Power Output: 2 × 140 Watts at 8 ohms
Total Harmonic Distortion: 0.08 % at rated power
IM Distortion: 0.08 % at rated power
Damping Factor: 100 at 8 ohms
Input Sensitivity and Impedance: 1 V, 50 kohms
Output Level and Impedance: 1 V, 10 kohms
Rated Speaker Impedance: 6 ohms MIN
Frequency Response: 10 Hz – 100 kHz, ±1 dB
Signal-to-Noise Ratio: 110 dB (IHF A, 0.5 V input)
GENERAL
Power Supply: AC 120 V, 60 Hz
Power Consumption: 2.5 A
Dimensions (W × H × D): 435 × 145 × 316 mm
17-
1
/8" × 5-
11
/16" × 12-
7
/16"
Weight: 8.5 kg, 18.7 lbs.
Specifications and features are subject to change without notice.
#US_ADM-2.1_08.p65 8/25/00, 6:22 PM8

Integra ADM-2.1 Specifications

Amplifier Section

power output at 8 ohms	100 Watts per channel
power output at 6 ohms	125 Watts per channel
dynamic power output at 8 ohms	2 × 140 Watts
total harmonic distortion at rated power	0.08 %
IM distortion at rated power	0.08 %
damping factor at 8 ohms	100
input sensitivity and impedance	1 V, 50 kohms
output level and impedance	1 V, 10 kohms
rated speaker impedance	6 ohms MIN
frequency response	10 Hz – 100 kHz, ±1 dB
signal-to-noise ratio	110 dB (IHF A, 0.5 V input)

General

power supply	AC 120 V, 60 Hz
power consumption	2.5 A
dimensions (W × H × D)	435 × 145 × 316 mm
weight	8.5 kg
