Integra DRX-2.4 User Manual

123
SetupSetup
6. Hardware
 6. 12V Trigger B
Set when outputting the control signal (maximum 12 V/25 mA) through the 12V
TRIGGER OUT B jack. Different settings can be set for each input selector. You
can enable power link operation when you connect the unit and the external
devices equipped with 12V trigger input jack.
 Delay (Default Value: 1sec)
Set after how many seconds the 12V trigger output will occur in response to
the unit's operation. As some devices cause a large current when they turn on,
delay the output if such devices are connected. Select a value between "0 sec"
to "3 sec".
 BD/DVD (Default Value: Zone 2)
GAME (Default Value: Zone 2)
CBL/SAT (Default Value: Zone 2)
PC (Default Value: Zone 2)
STRM BOX (Default Value: Zone 2)
AUX (Default Value: Off)
CD (Default Value: Zone 2)
TV (Default Value: Zone 2)
PHONO (Default Value: Zone 2)
TUNER (Default Value: Zone 2)
NET (Default Value: Zone 2)
BLUETOOTH (Default Value: Zone 2)
Set the 12V trigger output setting to each input.
Off
When the control signal is not output
Main
When controlling the power of external devices linked to the
input selection in the main room
Zone 2
When controlling the power of external devices linked to the
input selection in ZONE 2
Main/Zone 2
When controlling the power of external devices linked to the
input selection in the main room or in ZONE 2
 7. 12V Trigger C
Set when outputting the control signal (maximum 12 V/25 mA) through the 12V
TRIGGER OUT C jack. Different settings can be set for each input selector. You
can enable power link operation when you connect the unit and the external
devices equipped with 12V trigger input jack.
 Delay (Default Value: 2sec)
Set after how many seconds the 12V trigger output will occur in response to
the unit's operation. As some devices cause a large current when they turn on,
delay the output if such devices are connected. Select a value between "0 sec"
to "3 sec".
 BD/DVD (Default Value: Main/Zone 2)
GAME (Default Value: Main/Zone 2)
CBL/SAT (Default Value: Main/Zone 2)
PC (Default Value: Main/Zone 2)
STRM BOX (Default Value: Main/Zone 2)
AUX (Default Value: Main)
CD (Default Value: Main/Zone 2)
TV (Default Value: Main/Zone 2)
PHONO (Default Value: Main/Zone 2)
TUNER (Default Value: Main/Zone 2)
NET (Default Value: Main/Zone 2)
BLUETOOTH (Default Value: Main/Zone 2)
Set the 12V trigger output setting to each input.
Off
When the control signal is not output
Main
When controlling the power of external devices linked to the
input selection in the main room
Zone 2
When controlling the power of external devices linked to the
input selection in ZONE 2
Main/Zone 2
When controlling the power of external devices linked to the
input selection in the main room or in ZONE 2
