Integra DRX-2.4 - Speaker Combinations

158
Appendix
Speaker Combinations
• Up to two powered subwoofers can be connected in either combination.
Speaker Channels FRONT CENTER SURROUND
SURROUND
BACK
HEIGHT Bi-AMP
ZONE 2
(ZONE SPEAKER)
2.1 ch
(*1) (*1)
3.1 ch
(*1) (*1)
4.1 c h
(*1) (*1)
5.1 ch
(*1) (*1)
6.1 ch
(*2)
7.1 ch
(*2)
2.1.2 ch
(*3) (*1) (*3) (*1)
3.1.2 ch
(*3) (*1) (*3) (*1)
4.1. 2 ch
(*4)
5.1.2 ch
(*4)
(*1) You can select either Bi-AMP or ZONE SPEAKER.
(*2) When audio is being output from the ZONE SPEAKER, surround back speakers cannot play audio.
(*3) When using Bi-Amp speakers, it is necessary to connect the Bi-Amp speakers to the HEIGHT terminals, and height speakers to the SURROUND terminals.
(*4) When audio is being output from the ZONE SPEAKER, height speakers cannot play audio.
