Appendix
General Specications
Amplier Section North American models Australian and Asian models
Rated Output Power
With 8 ohm loads, both channels driven, from 20-
20,000 Hz; rated 80 watts per channel minimum
RMS power, with no more than 0.08% total harmonic
distortion from 250 milliwatts to rated output. (FTC)
7 ch × 135 W at 6 ohms, 1 kHz, 1 ch driven of 1% THD
(IEC)
Maximum Effective Output Power 170 W at 6 ohms, 1 kHz, 1 ch driven of 10% THD
7 ch × 160 W at 6 ohms, 1 kHz, 1 ch driven of 10% THD
(JEITA)
Dynamic Power (IEC60268-Short-term
maximum output power)
160 W (3 Ω, Front), 125 W (4 Ω, Front), 85 W (8 Ω, Front)
THD+N (Total Harmonic Distortion + Noise) 0.08% (20 Hz - 20,000 Hz, Rated output power)
Input Sensitivity and Impedance 200 mV/47 kΩ (LINE(RCA)), 3.5 mV/47 kΩ (PHONO MM)
Rated RCA Output Level and Impedance
PRE OUT (SUBWOOFER) : 1 V/470 Ω
ZONE B LINE OUT, ZONE 2 PRE/LINE OUT (*) : 200 mV/470 Ω
*1 V/470 Ω if changed to PRE OUT (FRONT)
Phono Maximum Input Signal Voltage 70 mV (MM 1 kHz 0.5%)
Frequency Response 10 Hz - 100 kHz/+1 dB, –3 dB (Direct)
Tone Control Characteristics ±10 dB, 20 Hz (Bass), ±10 dB, 20 kHz (Treble)
Signal to Noise Ratio 106 dB (IHF-A, LINE IN, SP OUT), 80 dB (IHF-A, PHONO IN, SP OUT)
Speaker Impedance 4 Ω - 16 Ω
Headphone Rated Output 80 mW + 80 mW (32 Ω, 1 kHz, 10% THD)
Supported impedance of Headphones 8 Ω - 600 Ω
Headphones Frequency Response 10 Hz - 100 kHz
