Audio Outputs North American models Australian and Asian models
Analog
PRE/LINE OUT (ZONE 2)(*) × 1
PRE OUT (SUBWOOFER) × 2
*Can be changed to LINE OUT (ZONE B) and PRE OUT (FRONT).
Speaker Outputs
9 (FRONT L/R, CENTER, SURROUND L/R, HEIGHT L/R or SURROUND BACK L/R, ZONE 2 L/R)
• North American models are banana plug ready.
Phones 1 (ø 6.3 mm, 1/4")
Others North American models Australian and Asian models
Setup Mic 1 (Front)
RS-232 1
12V TRIGGER OUT 3 (A:100 mA, B:25 mA, C:25 mA)
IR 2 (IN), 1 (OUT)
Specications and features are subject to change without notice.
