DTA-9.4
3
1 4
5
2
DISASSEMBLING PROCEDURES-2
REMOVE A POWERB AMP. UNIT AND A POWER SUPPLY UNIT FROM CHASSIS
Remove the three screws.
Rear panel
Remove the four screws.
Remove the eight screws.
Front side
Front side
Power supply unit
Move the power supply unit to front side.
Take out a power amp. unit from the chassis.
Power amp. unit
Front side
