DTA-9.4
9
7 11
12
8
10
DISASSEMBLING PROCEDURES-3
REMOVE A POWERB AMP. UNIT AND A POWER SUPPLY UNIT FROM CHASSIS
Remove the four screws.
Remove the four screws.
Remove the two screws.
Power supply unit
Move the power supply unit to up side.
By removing each screw of three copper plates
(RETAINER), You can remove an amplifier unit
completely.
NAPS-7788
Soldering side
Power supply unit
