Integra DTA-9.4 Service Manual

EXPLODED
V
IEW PARTS
LIST
DTA-9.4
REF NO. PART NAME DESCRIPTION PART NO. NOTE
A001 F BRACKET . 27111311
A002 SCREW 3TTB+8B(BC) 838430088
A003 HOLDER (BUSHING) TB-1116 27190635
A005 NUT . --- NOT SUPPLY
A006 CHASSIS . 27100429A
A007 SCREW 3TTB+8B(BC) 838430088
A008 CLAMP WS-2NS 27300833
A009 HOLDER KGLS-22RT 27190772
A010 HOLDER (BASE-AMP) 27191187A
A011 HEAT SINK (AMP) 27160523A
A012 SCREW 3TTB+8B(BC) 838430088
A013 SCREW 3TTB+8B(BC) 838430088
A014 SCREW 3TTB+8B(BC) 838430088
A016 CAP (SCREW) 28330135A
A017 SHLD PLT . 27150486
A018 SCREW 3TTW+8B(BC) 831430088 COREx2
A019 SCREW 3P+10FN(BC) 82143010 MAIN PSW
A020 SCREW 3TTB+8B(BC) 838430088
A021 RETAINER (TR) 27141868A
A022 BUSHING . 28170077
A023 HEAT SINK (POW-1) 27160521A
A024 RETAINER (HT) 27141832
A025 SCREW 3TTB+8B(BC) 838430088 A024x6,PCBx6
A026 SCREW 3TTS+16B(BC) 834430168
A027 SCREW 3SMS8W.SW+14B(BC) 801433
A030 HEAT SINK (POW-2) 27160522A
A031 RETAINER (HT) 27141832
A032 SCREW 3TTB+8B(BC) 838430088 A031x6,PCBx6
A035 SCREW 3TTS+16B(BC) 834430168
A037 SCREW 3SMS8W.SW+14B(BC) 801433
A038 SCREW 3TTB+8B(BC) 838430088
A039 SCREW 3TTB+8B(BC) 838430088 3307-12
A041 RETAINER (BUS-18) 27141852
A041a RETAINER (BUS-18) 27141852-1
A042 RETAINER (BUS-19) 27141853
A043 RETAINER (BUS-20) 27141854
A044 SCREW 3TTC+8B(Cu) --- NOT SUPPLY
A045 SCREW 3TTB+8B 838130088
A047 HOLDER (BASE-POW) 27191186
A049 SCREW 3TTB+10B(BC) 838430108
