Appendix
En-83
Audio components can be connected by using any of the
following audio connection formats: analog, optical,
coaxial, or HDMI.
When choosing a connection format, bear in mind that the
AV receiver does not convert digital input signals for
analog line outputs and vice versa.
If signals are present at more than one input, the inputs will
be selected automatically in the following order of priority:
HDMI, digital, analog.
*1
Depends on the “Audio TV Out” setting (➔ page 59).
*2
This is possible when “Audio Return Channel” is set to
“Auto” (➔ page 59), the TV/CD input selector is selected,
and your TV is ARC capable.
Tip
• When a signal is input via HDMI and the corresponding input
selector is selected, the HDMI indicator lights. In the case of an
optical or coaxial connection, the DIGITAL indicator lights. In
the case of an analog connection, neither of the HDMI and
DIGITAL indicators light.
Audio Connection Formats
IN
OUT
Blu-ray Disc/DVD player, etc.
AV receiver
TV, projector, etc.
HDMICoaxial Analog
Audio Signal Flow Chart
HDMI
Optical
*1
*1 *1
*1 *2
The following tables show how video signals at different resolutions are output by the AV receiver.
NTSC/PAL
✔: Output
s
*1
Available resolutions: [3840 × 2160 24/25/30 Hz], [4096 × 2160 24 Hz]
Video Resolution Chart
HDMI
4K
*1
1080p/24 1080p 1080i 720p 480p/576p 480i/576i
HDMI 1080p/24 ✔✔
1080p ✔✔✔
1080i ✔✔✔✔✔
720p ✔✔✔✔✔
480p/576p ✔✔✔✔✔✔
480i/576i ✔✔✔✔✔✔✔
Component 1080p
1080i
720p
480p/576p
480i/576i ✔✔✔✔✔✔✔
Composite 480i/576i ✔✔✔✔✔✔✔
Component Composite
1080p 1080i 720p 480p/576p 480i/576i 480i/576i
HDMI 1080p/24
1080p
1080i
720p
480p/576p
480i/576i
Component 1080p ✔
1080i ✔
720p ✔
480p/576p ✔
480i/576i ✔
Composite 480i/576i ✔
Output
Input
Output
Input
