Integra RDC-7.1 - Connecting a Power Amplifier

2
You can connect the RDC-7.1 (PRE OUT A terminals) and the power amplifier through RCA terminals using RCA type
audio pin cables. Also you can connect the amplifiers through XLR (Balanced) type terminals using XLR type cables.
The figure below illustrates the connection to the RDA-7.1, a power amplifier of the same product series. For connecting
speakers, refer to the instruction manual that comes with your amplifier.
Connecting through RCA type PRE OUT A terminals
Connecting through XLR (Balanced) type PRE OUT A terminals
Connecting a Power Amplifier
