Specifications
- 14 -
English
Specifications
General
Channels Refer to the frequency bands table at page 12
Frequency band 27 MHz Citizen Band
Frequency control P.L.L.
Operatine temperature -10°/+55°C
DC input voltage 9.0V (6 x AAA 1.5V alkaline battery)
7.2V (6 x AAA 1.2V Ni-MH battery)
Size 68 (L) x 146 (H) x 38 (D) mm
Weight 218 gr. (without batteries and antenna)
Receiver
System Double conversion, CPU controlled super-eterodine
IF 1° 10.695 MHz / 2° 455 KHz
Sensitivity 0.5uV for 20dB SINAD (FM)
0.7uV for 20dB SINAD (AM)
Audio output 0.3W at 8 ohm
Audio distorsion <8% at 1 KHz
Image rejection 61dB
Adjacent channel 61dB
Signal/noise ratio 45dB
Current drain 70mA (stand-by)
Transmitter
System CPU controlled P.L.L. systhesizer
Maximum RF power 4W at 9.0Vdc
Modulation AM/FM
Impedance 50 ohm unbalanced
Current drain 1500mA (at no modulation)
