- 4 -
English
Controls, Indicators and Operation
A. Channel Number
Channel number indication (from 01 to 80, according to the selected frequency band).
B. Alpha-numeric Indication
Not available and not used indication on the radios for the European market.
C. Frequencu Readout
Full 5-digit frequency readout in KHz.
D. Transmitter RF Output Power
It indicates the selected transmitter RF output power (0.1W, 1.0W or 4.0W). The 4.0W RF output power level is available
only on the frequency bands where this power level is allowed.
E. Memory Channel Number (M1-M8)
It indicates the selected memory channel number, total 8 memory channels are available (M1-M8), if any.
F. EMG Icon
The EMG icon is lighted when one of the pre-programmed Emergency Channels has been selected.
G. DW Icon
The DW icon is lighted when the DW (DUAL WATCH) function has been enabled, in order to automatically monitor two
different channels.
H. SCAN Icon
The SCAN icon is lighted when the SCAN function has been enabled, in order to automatically search busy channels or
busy memory channels.
I. TX Icon
The TX icon is ligthed when radio is in the transmit mode.
L. RX Icon
The RX icon is ligthed when radio is in the receive mode.
M. ESP C E Icon
The ESP C E icon is lighted when the ESP (Electronic SPEECH PROCESSOR) function has been enabled.
N. Battery Level Indicator
It shows the current battery level condition.
O. FM Icon
The FM icon is lighted when radio has been set to the FM (Frequency Modulation) operating mode.
P. AM Icon
The AM icon is lighted when radio has been set to the AM (Amplitude Modulation) operating mode.
Q. LOCK Icon
The LOCK icon is lighted when the keypad lock function has been enabled.
R. S/RF/MOD Digital Bar Meter
The 10-bar digital meter indicates the received signal strength (S0 to S9+30) in the receive mode.
It indicates the transmitter RF output power (0 to 4W) or the modulation level in the transit mode.
