3-10 PC Health Status
This section shows the Status of you CPU, Fan, Warning for overall system status. This is
only available if there is Hardware Monitor onboard.
CMOS Setup Utility – Copyright(C) 1984-2000 Award Software
PC Health Status
Item Help
CPU Warning Temperature Disabled
Shutdown Temperature Disabled
Show PC Health in Post Enabled
Current System Temp. 28
°
C/82
°
F
Current CPU Temperature 29
°
C/84
°
F
Current CPUFAN Speed 4687 RPM
Current SYSFAN Speed 0 RPM
Vcore 1.69V
Vcc3.3 3.31V
+ 5V 5.00V
+12V + 12.02V
-12V - 12.16V
5VSB(V) 5.45V
Menu Level >
↑↓→←
Move Enter:Select Item +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Optimized Defaults F7:Standard Defaults
Show PC Health in Post
During Enabled, it displays information list below. The choice is either Enabled or Disabled
Current CPU Temperature/Current System Temp/Current CPUFAN, SYSFAN Speed/
Vcore/ Vcc/3.3V/+5V/+12V/-12V/5VSB(V)
This will show the CPU/FAN/System voltage chart and FAN Speed.
3-11 Frequency/Voltage Control
This section is for setting CPU Frequency Control.
CMOS Setup Utility – Copyright(C) 1984-2000 Award Software
Frequency/Voltage Control
Item Help
Cyrix III Clock Ratio Default
Auto Detect DIMM/PCI Clk Enabled
Spread Spectrum Disabled
CPU Host/DRAM Clock Default
CPU Clock Ratio Jumpless x 3.0
Menu Level >
CyrixIII CPU Ratio
Adjust
↑↓→←
Move Enter:Select Item +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Optimized Defaults F7:Standard Defaults
