1-2 Specification
Spec Description
Design
∗
Micro ATX form factor 4 layers PCB size: 24.5x19.0cm
Chipset
∗
SiS 630T Chipset
Clock Generator
∗
Support 66/100/133MHz system Bus Clock (CPU Bus
Clock)
Support 100/133 MHz system memory clock
Support 33MHz PCI Bus clock
CPU Socket
∗
Support Pentium

III 500
∼
1.2GHz processor
∗
Support Celeron

533~1.0GHz processor
∗
Support 66, 100 and 133MHz CPU Bus clock
∗
Reserves support for future Intel Pentium

III processors
Memory Socket
∗
168-pin DIMM socket x2
∗
PC-100/PC-133 SDRAM
∗
Expandable to 1GB
∗
Support 3.3V SDRAM DIMM
Expansion Slot
∗
32-bit PCI slot x3, 2.2 Specification Compliant
∗
AMR slot x1
Integrate VGA
∗
3D graphic acceleration
∗
VGA Memory Selectable by BIOS from 2MB to 64MB
Integrate IDE
∗
2 channel of Bus Master IDE port supporting ULTRA DMA
33/66/100 MB/s ATA100 mode devices
Integrate LAN
(Only for 630TCF)
∗
Fast Ethernet Controller 10/100 Mbps
Audio
∗
AC’97 Digital Audio controller integrated
∗
AC’97 Audio CODEC on board
∗
Audio driver and utility included
BIOS
∗
Award 2MB Flash ROM
Multi I/O
∗
PS/2 keyboard and PS/2 mouse connectors
∗
Floppy disk drive connector x1
∗
Parallel port x1
∗
Serial port x2
∗
USB connector x2
∗
USB headers x2 (connecting cable option)
∗
Audio connector (Line-in, Line-out & Game Port)
