Intel Desktop Board DH55TC Product Guide
54
Setting the BIOS Configuration Jumper
NOTE
Always turn off the
power and unplug
the power cord from
the computer before
moving the jumper. Moving the jumper wi
th the power on may
result in
unreliable
computer operation.
Figure 27 shows t
he location
of the Desktop Board’s BIOS
confi
guratio
n jumper block.
Figure 27. Location of t
he BIOS Configuration Jumper Block
