Intel Desktop Board DQ67SW Technical Product Specification
10
Table 1. Feature Summary (continued)
Peripheral
Interfaces
• Fourteen USB ports:
― Two USB 3.0 ports are implemented with stacked back panel
connectors (blue)
― Four USB 2.0 ports are implemented with stacked back panel
connectors (black)
― Eight USB 2.0 front panel ports are implemented through four dual-port
internal headers
• Six SATA interfaces through the Intel Q67 Express Chipset with Intel
®
Rapid
Storage Technology RAID support:
― Two internal SATA 6 Gb/s ports (blue)
― Two internal SATA 3 Gb/s ports (black)
― Two backpanel eSATA 3 Gb/s ports (red)
• One serial port header
• Two IEEE 1394a ports:
― One IEEE 1394a port header
― One back panel IEEE 1394a port
Legacy I/O Control
• Nuvoton* W83677HG-i Super I/O controller for hardware management and
serial port support
BIOS
• Intel
®
BIOS resident in the SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
Instantly Available
PC Technology
• Support for PCI* Local Bus Specification Revision 2.2
• Support for PCI Express*
• Suspend to RAM support
• Wake on PCI, PCI Express, LAN, front panel, serial, and USB ports
LAN Support Gigabit (10/100/1000 Mbits/s) LAN subsystem using the Intel
®
82579LM Gigabit
Ethernet Controller
Expansion
Capabilities
• One PCI Express 2.0 x16 add-in card connector
• One PCI Express 2.0 x4 add-in card connector
• One PCI Express 2.0 x1 add-in card connectors
• One Conventional PCI bus connector
Hardware Monitor
Subsystem
• Hardware monitoring through the Nuvoton I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers
• Two fan sense inputs used to monitor fan activity
• Fan speed control
Intel
®
vPro™
Technology
• Intel
®
Advanced Management Technology (Intel
®
AMT) 7.0
• Intel
®
Trusted Execution Technology (Intel
®
TXT)
• Intel
®
Fast Call for Help (Intel
®
FCFH)
• Intel
®
Virtualization Technology (Intel
®
VT)
• Intel
®
Virtualization for Directed I/O (Intel
®
VT-d)
• KVM Remote Control
NOTE
Nuvoton parts may be labeled as Winbond* on the board.
