Intel Desktop Board DQ67SW Technical Product Specification
46
Table 9. Component-side Connectors and Headers Shown in Figure 10
Item/callout
from Figure 10 Descript
ion
A PCI Conventional bus add-in card connector
B Front panel audio header
C PCI Express x4 bus add-in card connector
D Internal mono speaker header
E PCI Express x1 bus add-in card connector
F PCI Express x16 bus add-in card connector
G 12 V internal power connector (ATX12V)
H Processor fan header
I Serial port header
J Chassis intrusion header
K Front chassis fan header
L Main power connector (2 x 12)
M Alternate front panel power LED header
N Front panel header
O Intel MEBX Reset header
P SATA connectors
Q Front panel USB header
R Intel FCFH header
S Front panel USB header
T Front panel USB header
U Front panel USB header
V IEEE 1394a front panel header
W S/PDIF header
X Rear chassis fan header
