Intel Braswell Series User Manual

2
1-2 Specification
Spec
Description
Design
⚫
6 layers; PCB size: 17x 17 cm
Embedded CPU
⚫
Intel
®
Braswell *SoC CPU
*CPU model varies from different IPC options. Please consult your dealer
for more information of onboard CPU.
Memory Slot
⚫
1 * DDR3L SODIMM Slot for un-buffered *DDR3L 1600 MHz SDRAM,
expandable to 8GB
Expansion Slot
⚫
1* Full-size Mini-PCIE slot
⚫
1* PCIE x1 slot
⚫
1* SIM card slot
LAN Chip
⚫
Integrated with 2* Intel i211AT Gigabit Ethernet LAN chip
⚫
Support Fast Ethernet LAN function of providing 10/100/1000Mbps
Ethernet data transfer rate
Storage
⚫
1* SATAIII port (SATA1)
⚫
1*M.2 M-key, type-2242, SATA interface slot
Audio Chip
⚫
C-Media HS-100B USB Audio IC
BIOS
⚫
AMI 64MB Flash ROM
Rear I/O
⚫
1* 12V DC-in system power Jack
⚫
1* DVI-D port
⚫
1* HDMI port
⚫
2* Serial port (COM1/COM2,COM1 support RS232/422/485 function)
⚫
4* USB 3.0 port
⚫
2* RJ-45 LAN port
⚫
1* Line-out port
⚫
1* MIC port
Internal I/O
⚫
1* 2-Pin Internal 12V DC-in power connector
⚫
1* SATA Power-out connector
⚫
1* CPUFAN header & 2* SYSFAN header
⚫
1* Front panel audio header
