Intel Braswell Series User Manual

4
Motherboard Internal Diagram
Note: SODIMM module should be 1.35V DDRIII SODIMM and not exceeding 8GB total capacity.
Internal 12V DC-in
Power connector
SYSFAN1 Header
*DDR3L SODIMM Slot
(SODIMM1)
DVI-D Port
over HDMI Port
RJ-45 LAN Ports
over USB 3.0 Ports
Serial Ports
12V DC -in
Power Connector
Line-Out Port
over MIC Port
Full-size
Mini-PCIE
Slot (MPE)
Front Panel
Audio Header
PCI Express x1 Slot
SATAIII Port
SATA Hard Disk
Power-Out Connector
Power LED Header &
Speaker Header
SYSFAN2 Header
Front Panel
Header
Serial Port Headers
(COM3/4/5/6)
GPIO Header
Intel CPU
Full-size
Mini-SATA
Slot (MSATA1)
CPUFAN Header
SIM Card Slot
LVDS Inverter
SMBUS Header
LVDS Header
USB 2.0 Header
PS2KBMS
Header
LANLED Headers
