(4) GPIO1 (10-pin): GPIO Header
GPIO_0
GND
GPIO_2
GPIO_5
GPIO_33
GPIO_1
GPIO_3
2
Pin 1
VCC
GPIO_7
GPIO_35
(5) USB3 (9-pin): USB 2.0 Port Header
Pin 1
V
CC
-DATA
GND
+DATA
V
CC
NC
-DATA
GND
+DATA
