(6) USB4 (4-pin): USB 2.0 Port Header
Pin 1
VCC
-DATA
GND
+DATA
(7) SM_BUS (4-Pin): SM_BUS Header
Pin 1
SMBUS_DATA
GND
SMBUS_CLK
V
CC
