LCD Control
Primary IGFX Boot Display
The optional settings are: [VBIOS default]; [CRT]; [DVI/HDMI]; [LVDS1].
When user set it as [CRT], [DVI/HDMI], or [LVDS1], the following items will show
up for user to make further settings:
Secondary IGFX Boot Display
The optional settings are: [Disabled]; [CRT]; [DVI/HDMI]; [LVDS1].
Active LFP
The optional settings are: [Disabled]; [Enabled].
[Disable]: VBIOS does not enable LVDS.
[Enable]: VBIOS enable LVDS driver by integrated encoder.
*If user select [LVDS1] in ‘Primary IGFX Boot Display’ or ‘Secondary IGFX Boot
Display’, and set Active LFP as [Enabled], user can make further settings in the
following items show up:
LVDS1 Panel Type
Use this item to select panel resolution used by internal graphics device, by setting
the appropriate setting item.
The optional setting are: [VBIOS Default]; [640 x 480]; [800 x 600]; [1024 x 600];
[1024 x 768]; [1280 x 800]; [1280 x 1024]; [1366 x 768]; [1440 x 900]; [1400 x
1050(RB)]; [1400 x 1050]; [1600 x 900]; [1600 x 1200]; [1680 x 1050]; [1920 x
1080]; [1920 x 1200]; [2048 x 1536].
Backlight Control
The optional settings are: [PWM Inverted]; [PWM Normal].
LVDS1 Panel Color Depth
The optional settings are: [18 Bit]; [24 Bit].
► Memory Configuration
Press [Enter] to make settings for the following sub-items:
Memory Frequency Limiter
Use this item to set maximum memory frequency selection in Mhz.
The optional settings are [Auto]; [1067]; [1333].
