Intel Desktop Board D2550MUD2 Product Guide
14
Graphics Support
Integrated Graphics Subsystem
The Intel GMA 3650 integrated graphics subsystem features the following:
• 640 MHz core frequency
• High quality texture engine
 DX10.1c* and OpenGL* 3.0 compliant
 Hardware Pixel Shader 4.1
 Vertex Shader Model 4.1
• Video
 Blu-ray* 2.0
 J.264 and VC1 hardware decoder
 PAVP 1.1c
 HDCP 1.3
• Displays
 VGA
 Digital Visual Interface (DVI)
 Flat Panel
VGA
The Desktop Board supports analog displays with a back-panel VGA port.
The maximum supported resolution is 1920 x 1200 at a 60 Hz refresh rate.
Digital Visual Interface
The Desktop Board supports Digital Visual Interface (DVI) displays with a back-panel
DVI-D port.
The maximum supported resolution is 1900 x 1200 at a 60 Hz refresh rate. The DVI-D
port is compliant with the DVI 1.0 specification.
Flat Panel Display Support
The board supports flat panel displays based on the LVDS interface. Support is
provided by the following connectors and headers:
• LVDS interface connector
• Flat panel voltage selection header
• Flat panel display brightness connector
• Backlight inverter voltage selection header
The connectors and headers are shown in Figure 2.
For more information on flat panel display support, refer to the Intel Desktop Board
D2550MUD2 Technical Product Specification located at
http://www.intel.com/products/motherboard/index.htm
.
