Intel D33217GKE User Manual

Technical Reference
41
2.2.2.1 Signal Tables for the Connectors and Headers
Table 12. PCI Express Full-Mini Card Connector
Pin Signal Name Additional Signal Name
1 WAKE#
2 3.3 V
3 Reserved (Extra USB) +5 V_MINI
4 GND
5 Reserved (Extra USB) CARDIN
6 1.5 V
7 CLKREQ#
8 Reserved
9 GND
10 Reserved
11 REFCLK-
12 Reserved
13 REFCLK+
14 Reserved
15 GND
16 Reserved
17 Reserved (Extra USB) LP5-
18 GND
19 Reserved (Extra USB) LP5+
20 Reserved
21 GND
22 PERST#
23 PERn0
24 +3.3 V aux
25 PERp0
26 GND
27 GND
28 +1.5 V
29 GND
30 SMB_CLK
31 PETn0
32 SMB_DATA
33 PETp0
34 GND
35 GND
36 USB_D-
37 GND
38 USB_D+
continued
