Intel Desktop Board D33217GKE Technical Product Specification
46
2.3 BIOS Setup Configuration Jumper
CAUTION
Do not move a jumper with the power on. Always turn off the power and unplug the
power cord from the computer before changing a jumper setting. Otherwise, the board
could be damaged.
Figure 13 shows the location of the BIOS Setup Configuration jumper.
Table 17 describes the BIOS Setup configuration jumper settings for the three modes:
normal, configure, and recovery. When the jumper is set to configure mode and the
computer is powered-up, the BIOS compares the processor version and the microcode
version in the BIOS and reports if the two match.
Figure 13. Location of the BIOS Configuration Setup Jumper
