Product Description
17
1.3.1 Intel D425 Graphics Subsystem
1.3.1.1 Intel
®
Graphics Media Accelerator 3150 Graphics
Controller
The Intel GMA 3150 graphics controller features the following:
• 400 MHz core frequency
• High quality texture engine
DX9.0c* and OpenGL* 1.4 compliant
Hardware Pixel Shader 2.0
Vertex Shader Model 2.0
• 3D Graphics Rendering enhancements
1.6 dual texture GigaPixel/s max fill rate
16-bit and 32-bit color
Vertex cache
• Video
Software DVD at 30 fps full screen
DVMT support up to 256 MB
• Display
Supports analog displays up to 2048 x 1536 at 75 Hz refresh (QXGA)
Supports LVDS displays up to 1366 x 768 (single channel, 18 bpp) (D425KTW
only)
Dual independent display support with LVDS option (D425KTW only)
For information about Refer to
Obtaining graphics software and utilities Section 1.2, page 16
