Product Description
19
1.5 Intel
®
NM10 Express Chipset
The Intel NM10 Express Chipset provides interfaces to the processor and the USB,
SATA, LPC, LAN, PCI, and PCI Express interfaces. The Intel NM10 Express Chipset is a
centralized controller for the board’s I/O paths.
NOTE
The board is designed to be passively cooled in a properly ventilated chassis. Chassis
venting locations are recommended above the processor heatsink area for maximum
heat dissipation effectiveness.
The Intel NM10 Express chipset http://www.intel.com/products/desktop/chipsets/index.htm
Resources used by the chipset Chapter 2
1.5.1.1 Video Memory Allocation
Video memory is allocated from the total available system memory for the efficient
balancing of 2-D/3-D graphics performance and overall system performance. Dynamic
allocation of system memory to video memory is as follows:
• 256 MB total RAM results in 32 MB video RAM
• 512 MB total RAM results in 64 MB video RAM
• 1 GB total RAM results in 128 MB video RAM
• 2 GB total RAM results in 224 MB video RAM
1.5.1.2 Analog Display (VGA)
The VGA port supports analog displays. The maximum supported resolution is 2048 x
1536 (QXGA) at a 75 Hz refresh rate.
1.5.1.3 Flat Panel Interface (LVDS) - D425KTW Only
The flat panel interface (LVDS) supports the following:
• Panel support up to UXGA (1366 x 768)
• 25 MHz to 112 MHz single–channel; @18 bpp
TFT panel type
• Panel fitting, panning, and center mode
• CPIS 1.5 compliant
• Spread spectrum clocking
• Panel power sequencing
• Integrated PWM interface for LCD backlight inverter control
