Intel Desktop Board D425KT and Intel Desktop Board D425KTW Technical Product
Specification
46
Table 21. Front Panel USB Header
Pin Signal Name Pin Signal Name
1 +5 VDC 2 +5 VDC
3 D- 4 D-
5 D+ 6 D+
7 Ground 8 Ground
9 KEY (no pin) 10 No Connect
Table 22. Front Panel USB Header with Intel Z-U130 USB Solid-State Drive or
Compatible Device Support (D425KTW only)
Pin Signal Name Pin Signal Name
1 +5 VDC 2 NC
3 D- 4 NC
5 D+ 6 NC
7 Ground 8 NC
9 KEY (no pin) 10 LED#
