Intel D54250WYK User Manual

Product Description
33
1.11.1.2 Wake-up Devices and Events
Table 11 lists the devices or specific events that can wake the computer from specific
states.
Table 11. Wake-up Devices and Events
Devices/events that wake up the system… …from this sleep state
Power switch S3, S4, S5
(
Note 1)
RTC alarm S3, S4, S5
(Note 1)
LAN S3, S4, S5
(Note 1)
USB S3
(Note 2)
WAKE# S3, S4, S5
(Note 1)
Consumer IR S3, S4, S5
(Note 3)
Notes:
1. S4 implies operating system support only.
2. USB ports must be turned off during S4/S5 states.
3. When Deep S4/S5 is enabled only Wake from RTC and Power Switch is supported.
NOTE
The use of these wake-up events from an ACPI state requires an operating system that
provides full ACPI support. In addition, software, drivers, and peripherals must fully
support ACPI wake events.
1.11.2 Hardware Support
The board provides several power management hardware features, including:
• Wake from Power Button signal
• Instantly Available PC technology
• LAN wake capabilities
• Wake from USB
• WAKE# signal wake-up support
• Wake from S5
• Wake from CIR
• +5 V Standby Power Indicator LED
NOTE
The use of Wake from USB from an ACPI state requires an operating system that
provides full ACPI support.

Intel D54250WYK Specifications

General

Socket	Soldered-down BGA
Number of Internal Drives Supported	2
TDP	15 W
Intel® vPro™ Technology	No
Intel® Visual BIOS	Yes
Intel® Boot Agent	Yes
Number of SATA Ports	2
Number of USB Ports	8
Integrated Bluetooth	Yes
Consumer Infrared Rx Sensor	Yes
HDMI Port Quantity	1
Mini DisplayPort Quantity	1
Number of Displays Supported	3
Total Memory Size	16 GB
Number of Memory Channels	2
Max Memory Bandwidth	25.6 GB/s
Number of DIMMs	2
ECC Memory Supported	No
Supported Operating Systems	Windows 8.1, Windows 8, Windows 7
Board Form Factor	UCFF
Internal Drive Form Factor	2.5" SSD or HDD
DC Input Voltage Supported	12-19 V
Processor Included	Intel Core i5-4250U
RAID Configuration	No
USB Revision	USB 3.0
Integrated Wireless	Intel Dual Band Wireless-AC 7260
Memory Types	DDR3L 1333/1600 1.35V SO-DIMM
Integrated LAN	Gigabit Ethernet
