Intel NUC Board D54250WYB and Intel NUC Board D34010WYB
Technical Product Specification
42
2.2.4.1 Signal Tables for the Connectors and Headers
Table 14. PCI Express Full-/Half-Mini Card Connector
Pin Signal Name Additional Signal Name
1 WAKE#
2 3.3 V
3 Reserved
4 GND
5 Reserved
6 1.5 V
7 CLKREQ#
8 Reserved
9 GND
10 Reserved
11 REFCLK-
12 Reserved
13 REFCLK+
14 Reserved
15 GND
16 Reserved
17 Reserved
18 GND
19 Reserved
20 Reserved
21 GND
22 PERST#
23 PERn0
24 +3.3 V aux
25 PERp0
26 GND
27 GND
28 +1.5 V
29 GND
30 SMB_CLK
31 PETn0
32 SMB_DATA
33 PETp0
34 GND
35 GND
36 USB_D-
37 GND (mSATA) Vendor
38 USB_D+
continued

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intel D54250WYK and is the answer not in the manual?

Intel D54250WYK Specifications

General IconGeneral
SocketSoldered-down BGA
Number of Internal Drives Supported2
TDP15 W
Intel® vPro™ TechnologyNo
Intel® Visual BIOSYes
Intel® Boot AgentYes
Number of SATA Ports2
Number of USB Ports8
Integrated BluetoothYes
Consumer Infrared Rx SensorYes
HDMI Port Quantity1
Mini DisplayPort Quantity1
Number of Displays Supported3
Total Memory Size16 GB
Number of Memory Channels2
Max Memory Bandwidth25.6 GB/s
Number of DIMMs2
ECC Memory SupportedNo
Supported Operating SystemsWindows 8.1, Windows 8, Windows 7
Board Form FactorUCFF
Internal Drive Form Factor2.5" SSD or HDD
DC Input Voltage Supported12-19 V
Processor IncludedIntel Core i5-4250U
RAID ConfigurationNo
USB RevisionUSB 3.0
Integrated WirelessIntel Dual Band Wireless-AC 7260
Memory TypesDDR3L 1333/1600 1.35V SO-DIMM
Integrated LANGigabit Ethernet
