Intel Desktop Board D915GLVG Product Guide
14
Main Memory
NOTE
To be fully compliant with all applicable Intel
®
SDRAM memory specifications, the board should
be populated with DIMMs that support the Serial Presence Detect (SPD) data structure. If your
memory modules do not support SPD, you will see a notification to this effect on the screen at
power up. The BIOS will attempt to configure the memory controller for normal operation.
The desktop board supports dual or single channel memory configurations. Desktop Board
D915GLVG supports dual or single channel memory configurations defined in Table 3.
Table 3. Desktop Board D915GLVG Memory Configurations
Memory
Speed
Processor FSB frequency
(MHz)
Memory Speed Outcome
(MHz)
Intel
®
Pentium
®
4 processor
800 400
Intel Pentium 4 processor
DDR 400
Intel
®
Celeron
®
D processor
533 400
Pentium 4 processor 800 333
Pentium 4 processor
DDR 333
Intel Celeron D processor
533 333
Desktop board D915GLVG supports:
• Four 184-pin Double Data Rate (DDR) SDRAM Dual Inline Memory Module (DIMMs)
connectors with gold-plated contacts
• Unbuffered, non-registered single or double-sided DIMMs
• Serial Presence Detect (SPD) memory only
• Non-ECC RAM
• 2.5 V memory
• Memory configurations listed below:
⎯ Up to 1.0 GB utilizing 128 Mb technology
⎯ Up to 2.0 GB utilizing 256 Mb technology
⎯ Up to 4.0 GB utilizing 512 Mb or 1 GB technology
NOTE
System resources (such as PCI and PCI Express) require physical memory address locations that
reduce available memory addresses above 3 GB. This may result in less than 4 GB of memory
being available to the operating system and applications.
Related Links:
Go to the following links or pages for more information about:
• The latest list of tested memory, http://support.intel.com/support/motherboards/desktop/
• SDRAM specifications, http://www.intel.com/technology/memory/
• Installing memory, page 32 in Chapter 2
