Intel Desktop Board D945GNT/D945GTP Product Guide
34
6. Hold the processor with your thumb and index fingers oriented as shown in Figure 11. Make
sure fingers align to the socket cutouts (see
Figure 11, F). Align notches (see Figure 11, G)
with the socket see (
Figure 11, H). Lower the processor straight down without tilting or sliding
the processor in the socket.
OM17214
G
G
F
H
F
H
Figure 11. Install Processor
7. While pressing down on the load plate (Figure 12, I), close and engage the socket lever (Figure
12, J).
OM17215
I
J
Figure 12. Close the Load Plate
