Connecting Fan and Power Cables
Connecting Fan Cables
Figure 23 shows the location of the fan headers. Connect the processor’s fan heat sink cable to the
4-pin processor fan header on the board. Connect chassis fan cables to the 3-pin fan headers.
OM17621
3
1
2
4
3
1
2
4
AB
3
1
2
3
1
2
BA
OR
Figure 23. Location of Fan Headers
