Intel D915GMHLK - Desktop Board - Mainboard User Manual

Installing and Replacing Desktop Board Components
43
Connecting Internal Headers
Before connecting cables to the internal headers, observe the precautions in "Before You Begin" on
page
27. Figure 21 shows the location of the internal headers.
OM17620
USB A
USB B
Power (+5V)
Power (+5V)
D-
D+
Ground
Key (no pin)
N/C
D-
D+
Ground
5
6
7
8
3
4
2
10
1
Ground
Ground
TPA2+
TPA2-
TPA1-
TPA1+
+12 V
+12 V
Ground
Key
(no pin)
1394a
1
5
6
7
3
4
2
8
10
Port1L
Port1R
Port2R
Sense_Send
Port2L
GND
Presence#
Sense1_Ret
Key (no pin)
Sense2_Ret
1
5
6
7
3
4
2
10
9
On/Off
Power LED
HD LED
Reset
No Connection
1
2
3
4
5
7
6
8
9
1
3
F
E
D
C
B
12
A
Item Description
A Chassis intrusion
B Alternate power LED
C Front panel
D Hi-speed USB 2.0 (two)
E IEEE 1394a (two, optional)
F Front panel audio
Figure 21. Internal Headers
