Intel D945PLRN

Intel Desktop Board D945PLRN Product Guide
32
Installing and Removing Memory
The desktop board has two 240-pin DDR2 DIMM sockets arranged as DIMM 0 (blue) in both
Channel A and Channel B.
Guidelines for Dual Channel Memory Configuration
Before installing DIMMs, read and follow these guidelines for dual channel configuration.
Install a matched pair of DIMMs equal in speed and size in DIMM 0 of both channels A and B (see
Figure 13).
Channel A
1 GB, 533 MHz
DIMM 0
Channel B
1 GB, 533 MHz
DIMM 0
Figure 13. Dual Configuration
NOTE
All other memory configurations will result in single channel memory operation.
