Intel D945PLRN

Intel Desktop Board D945PLRN Product Guide
38
Connecting Internal Headers
Before connecting cables to the internal headers, observe the precautions in "Before You Begin" on
page
23. Figure 18 shows the location of the internal headers.
OM18133
USB A
USB B
Power (+5V)
Power (+5V)
D-
D+
Ground
Key (no pin)
N/C
D-
D+
Ground
5
6
7
8
3
4
2
10
1
Port1L
Port1R
Port2R
Sense_Send
Port2L
GND
Presence#
Sense1_Ret
Key (no pin)
Sense2_Ret
1
5
6
7
3
4
2
10
9
On/Off
Power LED
HD LED
Reset
No Connection
1
2
3
4
5
7
6
8
9
1
3
E
D
C
B
12
A
Item Description
A Chassis intrusion
B Alternate power LED
C Front panel
D USB 2.0 (two)
E Front panel audio
Figure 18. Internal Headers
