Table 2. Desktop Board DG31GL Components
Label Description
A PCI bus connector 2
B PCI bus connector 1
C Battery
D S/PDIF connector
E Back panel connectors
F 12 V processor core voltage connector (2 x 2 pin)
G Chassis fan header (3-pin)
H Processor socket
I Processor fan header (4-pin)
J DDR2 Channel A DIMM 0 socket
K DDR2 Channel B DIMM 0 socket
L Serial port header
M Diskette drive connector
N Main power connector (2 x 12 pin)
O IDE connector
P Serial ATA connectors (2)
Q Front panel header
R Alternate front panel power LED header
S BIOS configuration jumper block
T High-speed USB 2.0 headers (2)
U Speaker
V Front panel audio header
For more information go to the following locations:
• Supported processors
http://www.intel.com/go/findCPU
• Audio software and utilities
http://www.intel.com/design/motherbd
• LAN software and drivers
http://www.intel.com/design/motherbd
