Intel DG31GL - Desktop Board Essential Series Motherboard User Manual

Installing and Replacing Desktop Board Components
43
NOTE
The back panel line out connector is designed to power either headphones or amplified
speakers only. Poor audio quality may occur if passive (non-amplified) speakers are
connected to this output.
Connecting Chassis Fan and Power Supply
Cables
Connecting the Chassis Fan Cable
Connect a chassis fan cable to the 3-pin chassis fan header on the Desktop Board.
Figure 21 shows the location of the chassis fan header.
Figure 21. Location of the Chassis Fan Header
