Intel Desktop Board DG33BU Product Guide
12
Table 2. Desktop Board DG33BU Components
Label Description
A PCI bus connector 2
B Front panel audio header
C PCI bus connector 1
D PCI Express x1 connector
E Speaker
F PCI Express x16 connector
G Back panel connectors
H 12 V processor core voltage connector (2 x 2 pin)
I Rear chassis fan header (3-pin)
J Processor socket
K Processor fan header (4-pin)
L Serial header
M Main power connector (2 x 12 pin)
N Diskette drive connector
O DDR2 DIMM 0 sockets
P DDR2 DIMM 1 sockets
Q Battery
R Front chassis fan header (3-pin)
S Chassis intrusion header
T BIOS configuration jumper block
U Alternate front panel power LED header
V Front panel header
W Serial ATA connectors (4)
X High-speed USB 2.0 headers (3)
Y IDE connector
Z IEEE 1394a header
Related Links:
Go to the following links for more information about:
• Desktop Board DG33BU
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
• Supported processors
http://www.intel.com/go/findCPU
• Audio software and utilities
http://www.intel.com/design/motherbd
• LAN software and drivers
http://www.intel.com/design/motherbd
