Intel Desktop Board DH61CR Product Guide
44
Front Panel Audio Header
The front panel audio header shown in Figure 19, A supports both Intel High Definition
Audio and AC ’97 Audio.
Table 4 shows the pin assignments and
signal names for HD Audio and Table 5 shows
the pin assignments and signal names for AC ’97 Audio.
Table 4. Front Panel Audio Signal Names for Intel HD Audio
Pin Signal Name Pin Signal Name
1 PORT 1L (Microphone) 2 Ground
3 PORT 1R (Microphone) 4 PRESENCE#
5 PORT 2R (Headphone) 6 SENSE1_RETURN
7 SENSE_SEND 8 KEY (no pin)
9 PORT 2L (Headphone) 10 SENSE2_RETURN
Table 5. Front Panel Audio Header Signal Names for AC ’97 Audio
Pin Signal Name Pin Signal Name
1 MIC 2 AUD_GND
3 MIC_BIAS 4 PRESENCE#
5 FP_OUT_R 6 AUD_GND
7 No connection 8 KEY (no pin)
9 FP_OUT_L 10 AUD_GND
S/PDIF Header
Figure 19, B shows the location of the S/PDIF output header. Table 6 shows the pin
assignments and signal names for the S/PDIF output header.
Table 6. S/PDIF Header Signal Names
Pin Description
1 Ground
2 S/PDIF Out
3 Key (no pin)
4 +5 VDC

Intel DH61CR Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	2
Max Memory	16 GB
Memory Standard	DDR3 1066/1333
PCIe x16 Slots	1
PCIe x1 Slots	2
PCI Slots	1
RAID Support	No
SATA Ports	4 x SATA 3Gb/s
USB Ports	4 x USB 2.0
VGA	1 x VGA
DVI	Yes
