Intel DH61HO - Component-Side Connectors and Headers Shown in Figure 9

Intel Desktop Board DH61HO Technical Product Specification
40
Table 11. Component-side Connectors and Headers Shown in Figure 9
Item/callout
from Figure 1 Description
A PCI Express 2.0 x1 bus add-in card connector
B PCI Express 2.0 x1 bus add-in card connector
C PCI Express 3.0 x16 bus add-in card connector
D Rear chassis fan header
E 12 V processor core voltage connector (2 X 2)
F Processor fan header
G Main power connector (2 x 12)
H SATA connectors
I Front panel header
J Front panel USB 2.0 header
K Front panel USB 2.0 header
L Serial port header
M Front panel audio header
