Intel Desktop Board DH61HO Technical Product Specification
42
Table 16. SATA Connectors
Pin Signal Name
1 Ground
2 TXP
3 TXN
4 Ground
5 RXN
6 RXP
7 Ground
Table 17. Fan Headers
Pin 4-Wire Support Pin 3-Wire Support
1 Ground 3 Ground
2 +12 V 2 +12 V
3 FAN_TACH 1 FAN_TACH
4 FAN_CONTROL N/A N/A
2.2.2.2 Add-in Card Connectors
The board has the following add-in card connectors:
• One PCI Express 3.0 x16 (3.0/2.x/1.x)
• Two PCI Express 2.0 x1 (2.x/1.x)
NOTE
PCI Express 3.0 is only supported by 3
rd
generation Intel Core Processor family
processors.
