Product Description
15
1.1.3 Board Layout (Bottom)
Figure 2 shows the location of the major components on the bottom-side of the board.
Figure 2. Major Board Components (Bottom)
Table 3. Components Shown in Figure 2
Item/callout from
Figure 2 Descri
ption
A Low Pin Count (LPC) Debug connector
