Product Description
17
1.2 Online Support
To find information about… Visit this World Wide Web site:
Intel Desktop Board DH77DF http://www.intel.com/products/motherboard/index.htm
Desktop Board Support http://www.intel.com/p/en_US/support?iid=hdr+support
Available configurations for Intel
Desktop Board DH77DF
http://ark.intel.com
Supported processors http://processormatc
h.intel.com
Chipset information http://www.intel.com/products/desktop/chipsets/index.htm
BIOS and driver updates http://downloadcenter.intel.com
Tested memory http://www.intel.com/support/motherboards/desktop/sb/CS-
025414.htm
Integration information http://www.intel.com/support/go/buildit
1.3 Processor
The board supports 3
rd
generation Intel Core processor family and 2
nd
generation Intel
Core processor family processors.
Other processors may be supported in the future. This board supports processors with
a maximum wattage of 95 W Thermal Design Power (TDP). The processors listed
below are only supported when falling within the wattage requirements of Intel
Desktop Board DH77DF. See the Intel web site listed below for the most up-to-date
list of supported processors.
For information about… Refer to:
Supported processors http://processormatch.intel.com
CAUTION
Use only the processors listed on the web site above. Use of unsupported processors
can damage the board, the processor, and the power supply.
NOTE
This board has specific requirements for providing power to the processor. Refer to
Section 2.5.1 on page 62 for information on power supply requirements for this board.
NOTE
Use of a 95 W TDP processor requires a custom thermal solution. Pairing a mini-ITX
chassis and a 95 W TDP processor with the supplied standard Intel thermal solution
may not meet thermal requirements. Verify that your thermal solution and chassis will
meet the necessary thermal requirements. Failing to do so will cause the processor to
throttle, significantly decreasing system performance.
